BERTBrain Gateway – Secure & Flexible Control

The BERTBrain Gateway is the central hub for managing BERT plug load and hardwired device controls. It supports both cloud-connected and on-premises deployments, providing robust, secure, and scalable infrastructure for your energy management needs.

Each gateway can handle up to 500 Berts. Gateways can be installed in a centralized location or distributed throughout individual buildings.

Case Studies Brochure

Deployment Options

Cloud-Connected (Recommended)

  • Automatic software updates and feature enhancements
  • Seamless scalability and centralized management
  • Extensive, real-time alerts and notifications
  • Remote diagnostics and support
  • Access to advanced integrations, including AI/ML analytics (coming soon)
  • Automated, off-site backup of schedule and energy usage data
  • Offline functionality – operates without cloud connection, ensuring reliability

On-Premises

  • Local-only data storage and processing
  • No external connectivity requirements

Hardware & Network Requirements

Static IP Address

  • All BERT devices communicate exclusively with the BERTBrain Gateway’s IP
  • Network Connection
  • Wired LAN strongly preferred for reliability and performance
  • Wi-Fi supported (WPA/WPA2-Enterprise or PSK, MAC authentication optional)

Storage

  • Minimum 128GB onboard (multi-year data retention)
  • Expandable via NAS or external USB drive
FeatureCloudOn-Premises
Automatic UpdatesYesManual/Local
Automatic BackupYesManual/Local
Remote SupportYesOptional (VPN required)
Remote ManagementYesOptional (VPN required)
External IntegrationsYesNo
Data ResidencyAWS (encrypted)Local Storage
Real-time AlertsYesLimited
SSO/OAuthYesYes
Network IsolationVLAN/Wi-Fi supportedVLAN/Wi-Fi supported
SecurityTLS, VPN, Signed UpdatesTLS, Signed Updates

Security Architecture

Gateway Security

No Public Inbound Access

  • All connections are outbound initiated only

Outbound Communication

  • HTTPS over TLS 1.2/1.3 (AES-256-GCM encryption, SHA-256 integrity)

Device Authentication

  • Device-specific API keys (securely provisioned and stored)
  • Mutual authentication for MQTT (port 8883, TLS)

Operating System Hardening

  • Read-only root filesystem
  • Signed OTA updates (RSA-2048 signatures)
  • Protection against unauthorized modifications

Cloud & Data Security

Cloud Infrastructure

  • Hosted on AWS, leveraging AWS best practices

Private Connectivity

  • AWS Site-to-Site VPN (IPsec with AES-256, SHA-256)

Data Encryption

  • All data encrypted in transit and at rest
  • HTTPS with AWS-managed certificates (ECDSA P-256 or RSA-2048)
  • MQTT over TLS with X.509 certificates
  • AWS Signature Version 4 (HMAC-SHA256) for API integrity
  • Network Segmentation & Device Isolation

Device Network Isolation

  • BERT devices can be placed on a dedicated VLAN or isolated subnet
  • MAC authentication and/or WPA/WPA2-Enterprise for wireless security

Identity & Access Management

Single Sign-On (SSO)

  • Agnostic to provider – supports third-party OAuth integrations

Role-Based Access

  • Granular permissions for local and remote management

Maintenance & Support

Automatic Updates

  • Cloud-connected gateways receive security patches and new features automatically

Remote Support

  • Secure remote diagnostics and troubleshooting (cloud)

Local Management

  • Basic functionality available offline for on-premises deployments

Additional Recommendations

IT Security

  • Place the Gateway and BERT Controls on a dedicated management VLAN (IoT)
  • Restrict outbound traffic to only required endpoints and ports
  • Regularly review device authentication credentials and update as needed

Scalability

  • Consider cloud mode for multi-site or enterprise-wide deployments
  • Use on-premises mode for air-gapped environments
